Straddle Leg Stacker SPN1030A-ES Semi Electric 3.0M Lift 1000KG

Accommodating a range of different loads, skids, racks and objects thanks adjustable base legs,  the SPN1030A-ES has a lifting height of 3m and a load capacity of 1000kg.

Main Features:

Adjustable base legs for lifting loads, skids, racks and objects.

Capacity 1000kg

Lifting Height 3000mm

Forks adjust from side to side to accommodate skid widths

Adjustable forks lower to the minimum height of 2 1/8".

Fork Length 1070mm

Fork Width 100mm

Sturdy and reliable mast made of rolled U-profiles. Hard chrome plated piston. Adjustable lifting chain. Powerful lift motor 2.1HP

Integrated 150AH maintenance free battery supplies strong power to effect frequent lifting task. An integrated charger facilitates easy and reliable charging of the integral battery.

On site assembly and training available

Full details can be downloaded in PDF format.

Please note purchase does not include assembly or training. If assembly or training is required please click on On Site Assembly or On Site Staff Training in Accessories at the top of the page.
